ARB Old Man Emu Leaf Springs
ARB 4x4 Accessories
Features
Reviews
Manufacturer
Features
- Heavy Duty
- Military Wrap
- Graphite coat
- Anti Friction Pads
- Anit Squeak Clamp Liners
- Sold Each
- California Residents: WARNING
PRODUCT OVERVIEW
Draw Tapered & Diamond Cut Leaves: Ensure the load is progressively distributed over a larger surface area, reducing the high stresses that develop at leaf ends. This provides increased ride quality and protection against leaf breakage, significantly increasing the spring life. Fully Scragged & Load Tested: Scragging ensures the spring takes a permanent 'set' which reduces the risk of sagging. Load testing ensures the spring meets the required specification. Graphite Coating: To further reduce the friction between the spring leaves & friction pads. Military Wrap: Designed to provide added safety. Anti Friction Pads: Regreasable nylon interleaf liners reduce friction at the leaf tips where the load is the greatest. Flat Axle Seat Area: Allows a positive, safe axle mount reducing spring stress & increasing spring life. Shot Peening: The tension side of all leaves is shot peened to reduce spring stress. This process can double the life of a spring. Two-stage Leaf Pack: Featured on most rear springs for optimum comfort. When unladen the vehicle is largely riding on the primary stage, with the secondary stage providing additional support when a heavy load is added.
Customer Reviews
Customer Images
4.2
4.2 112
63 Customer ratings
Customer Images
4.0
Decent spring, not perfect
It’s an alright spring, nothing special. Installed on a 2010 Tacoma with shell. Without a spacer it brought the rear end level with a 3” RC coil over shock in front. The ride is alright, but the spring still rides fairly flat which is not ideal for off roading or just daily driving.
By Michael
from Utah
| 4/18/21
5.0
Added additional leaf for higher lift/load rating
Got these put on with a set of King shocks and they feel great. The ride without the additional leaf was great and I notice almost no difference in ride quality with the additional leaf. They look great and do very well on and off road. Took measurements and there was NO sag after adding the additional weight of the RTT, which makes sense since they’re now rated to 600lb.
By NotMax
from Pittsburgh, PA
| 3/21/21
5.0
Love
These springs work for my 95.5 to 97 Tacoma website says they don’t. I highly recommend
By Anonymous
| 3/8/21
5.0
Tacoma Rear Lift
Nice springs and are doing the job as expected! Good lift :-) Helpful tech support when I called too with a question.
By Mike
from Florida
| 1/26/21
Q & A
See More Answers
Question & Answers
44 Answered questionsQ: Do these come with bushings? Answer this question
A: No they don't come with bushings. Just the leaf spring pack.
Answered by No Answer from No Answser on 01/15/2021
A: No it doesn’t
Answered by Dm101 from Houston Tx on 01/15/2021
A: They do not come with bushings
Answered by Jc1234 from Texas on 01/14/2021
Q: What size of bushings do these take? I’ve literally ordered over $60 worth of just bushings an they’ve all been wrong it’d be nice if there was a link cause it save me alot of money an time Answer this question
A: Skeeter, these ARB Old Man Emu leaf springs are meant to work with the factory XJ bushings. Here are some options we offer. Crown Automotive Leaf Spring Shackle Bushing (Part number: 52000504) Crown Automotive Main Eye Leaf Spring Bushing (Part number: 52000503)
Answered by Mario from Compton, CA on 12/04/2020
A: Moog sb371 and sb372
Answered by Mike on 12/03/2020
Q: What are all the additional parts and bits needed for a complete install of these springs? I've been told a sway bar relocation kit is required. How about U-bolts, Bushings, Shocks, Shackles? What's necessary? What stock equipment can stay? Answer this question
A: You'll want to replace the leaf spring bushings and your ubolts. I have extended shocks and 2" lift shackles on mine already so didn't need to replace shocks. I believe you can mount these without extended shackles and I have 2 " lift and didn't need any relocation of anything.
Answered by Anonymous from Denver on 11/11/2020
A: This is just one spring, so you would need to buy 2 springs. What else are you trying to do? Completely lift your vehicle 1"? Please call our support line so we can understand what you are trying to do so we can get you the correct parts Toll Free: 1-877-474-4821
Answered by Kelly from 4WP Corporate Headquarters on 11/09/2020
Q: Do you have the bolt plates for these leaf springs? Application is an '06 Hummer H3 GM # is 15295280... Answer this question
A: Bob Mac, unfortunately we do not have any replacement bolt plates specifically for the Hummer H3.
Answered by Mario from Compton, CA on 04/21/2021
Q: Is this part sold as a set? Answer this question
A: That is one leaf spring pack.
Answered by Kelly from 4WP Corporate Headquarters on 04/19/2021
Manufacturer
ARB has been manufacturing 4x4 parts for over 40 years. ARB Air Lockers will amplify the traction of your 4x4 on challenging trails. They give the off-road driver what she needs in traction, control and performance. ARB believes in its products so it offers a five year, unlimited mile warranty across the air locker range. ARB 4x4 Accessories includes the suspension system brand Old Man Emu, maker of premium off-road shock absorbers. Old Man Emu premium shocks are developed and tuned specifically for each vehicle application. They come complete with vehicle specific mounting kits for fuss free installation. ARB parts are all developed, engineered and fabricated in-house in Australia. Shop ARB 4x4 Accessories Now
